Hand gaussmeter SOLLAU GM G

Code: GAUSSMETR GM G
Not rated
€1 054,58 / pcs €871,55 excl. VAT
In Stock

Detailed information

Product detailed description

Complete functionality is enabled by using only 4 buttons. Saving data to PC by pressing the DATA key possible. The SOLLAU GM Gauss meter is characterized by simple operation and a favorable price/performance ratio.

The stated price is without calibration. If you wish to perform a calibration on the device, make a remark in your order. We will do a calibration for the price of 43 EUR without VAT.

Usage:

We offer a SOLLAU GM hand Gauss meter used for measuring DC and AC magnetic fields. Values measured are flux density (in tesla or gauss units) and field strength (in A/m). The SOLLAU GM is delivered with rechargeable batteries and is very suitable as a hand-held meter. For non-portable use, it is equipped with a power supply with a USB cable (included in the delivery), serving as a battery charger at the same time. With several built-in functions, it shows high measurement accuracy in both cases.

Description of the function

The SOLLAU GM Gauss meter is fitted by a transverse probe as standard. An axial and a thin transverse probe for measuring inside small gaps are also available. All probes are equipped with programmable EEPROM memories for identification, parameterization, and linearization. The measuring range for the flow density is up to 4.5 tesla and for the field strength 3,800 kA/m, resp. The resolution is set to 1 mT or 1 A/m.  Other characteristic features are: holding the maximum value (positive and negative), adjusting the linearity, balancing, and the battery status indicator with energy-saving mode. The measured values can be easily displayed and saved to your PC via the USB port by pressing the DATA key. The device can also be controlled automatically using a customer's software.

Technical parameters

 Display

 Graphics LCD

 Measuring Range

 Resolution

 Tesla [T]

 Gauss [G] -   Oersted [Oe]

 Amps/Meter  [A/m]

 4.5 T

 1 mT

 45 kG

 45 kOe

 10 G

 10 Oe

 3800  kA/m

 1  kA/m

 1 T

 100 mT

 1 kG

 1 kOe

 1 G

 1 Oe

 1000 kA/m

 100  A/m

 100 mT

 10 mT

 1 kG

 1 kOe

 100 mG

 100 mOe

 100 kA/m

 10 A/m

 10 mT

 1 mT

 100 G

 10 mG

 10 kA/m

 1 A/m

 Accuracy

 DC ±0.5 % up to 1.5 T and ±1 % from 1.5 T; Peak ±2 %; AC ±2 %

 Frequency Range

 DC / AC 0 Hz …5 kHz (r.m.s. value)

 Peak Hold

 t signal > 250 µs

 Interface

 USB; incl. software for easy data storage on a personal computer (included in delivery)

 Power Supply

 Power supply unit 100..240 VAC, 50/60 Hz, 0.3 Amax
USB interface
Rechargeable battery 2 x AA 1.2 V NiMH (exchangeable)
- completely included in delivery -

 Dimensions

 approx. 145 x 80 x 40 mm3

 Rozměry

 ca. 145 x 80 x 40 mm3

 Weight

 approx. 250g incl. battery, without probe

 Temperature Range

 -10°C .. +40°C (not bedewing)

 Measuring Probe

 Standard transversal probe N

 dimensions approx 3.5 x 1.35 x 46 mm3 (included in delivery)

 Axial Probe

 Dimensions approx. 4 mm Ø x 60 mm

 Transversal Probe S

 Dimensions approx. 3.5 x 0.75 x 46 mm3

 All Probes:

  • Active area Ø 0.15 mm
  • Holder approx. 11 mm Ø x 100mm
  • Cable length: 1.5 m (special lengths available)
  • Integrated EEPROM
