Plate magnet MS-MC-BF (310)

Code: MS-MC-BF260X310X100-133784 MS-MC-BF310X310X100-133785 MS-MC-BF360X310X100-133786 MS-MC-BF410X310X100-133787 MS-MC-BF460X310X100-133788 MS-MC-BF510X310X100-133789 MS-MC-BF610X310X100-133790 MS-MC-BF810X310X100-133791 MS-MC-BF1010X310X100-133792 Choose variant
Not rated
€448,63 / pcs €493,80 / pcs €574,46 / pcs €656,15 / pcs €767,22 / pcs €821,35 / pcs €982,76 / pcs €1 311,30 / pcs €1 640,82 / pcs from €448,63 / pcs €370,77 excl. VAT €408,10 excl. VAT €474,76 excl. VAT €542,27 excl. VAT €634,07 excl. VAT €678,80 excl. VAT €812,20 excl. VAT €1 083,72 excl. VAT €1 356,05 excl. VAT from €370,77 excl. VAT
On request In Stock In Stock In Stock On request On request On request In Stock On request Choose variant
Variant

Length: 260-1010 mm | Width: 310 mm | Height: 100 mm | Ferrite design

Detailed information

Product detailed description

FERRITE PLATE MAGNETS
DIMENSIONAL TABLE
CATALOG NUMBER Length A (mm) Width B (mm) Height C (mm) Thread Height of suspension (mm) Magnetic induction (G) Type of magnets Weight (kg)
MS-MC-BF260X310X100-133784 260 310 100 4 x M8 150 2 800 Ferrite magnets 42,5
MS-MC-BF310X310X100-133785 310 310 100 4 x M8 150 2 800 Ferrite magnets 50,5
MS-MC-BF360X310X100-133786 360 310 100 4 x M8 150 2 800 Ferrite magnets 59,5
MS-MC-BF410X310X100-133787 410 310 100 4 x M8 150 2 800 Ferrite magnets 67,5
MS-MC-BF460X310X100-133788 460 310 100 4 x M8 150 2 800 Ferrite magnets 76
MS-MC-BF510X310X100-133789 510 310 100 6 x M8 150 2 800 Ferrite magnets 84
MS-MC-BF610X310X100-133790 610 310 100 6 x M8 150 2 800 Ferrite magnets 100,5
MS-MC-BF810X310X100-133791 810 310 100 8 x M8 150 2 800 Ferrite magnets 133,5
MS-MC-BF1010X310X100-133792 1010 310 100 8 x M8 150 2 800 Ferrite magnets 166



The plate magnet serves as a simple magnetic separator. Its main advantage is easy installation also with self-help.

The plate magnet is fitted with ferrite magnets, but we can equip it with the strongest neodymium magnets, too.

Not satisfied with the size or strength of the plate magnet? Need some alterations? Please contact us. We will prepare a tailor-made offer for you!
